Portable Ultrasonic Flowmeter UFP-20

製品詳細
Portable Ultrasonic Flowmeter UFP-20 Now Comes, Versatility ! Functionality ! Reliability !
The Portable Ultrasonic Flowmeter UFP-20, based on the same, ergonomically advanced design so popular in the UFP-10, features significant size reduction. The result is a portable ultrasonic flowmeter that meets next-generation standards.The UFP-20's single-handed portability means difficult and challenging jobs located in narrow or high places can now be performed safely and easily.


Operation Manual Product data sheets[PDF] Engineering Specifications[doc] How to Use[Video]

The flowmeter includes a thickness measurement function and can effectively measure the sound velocity of fluids. Measurement data can be printed, logged or transferred to a computer which can assist data collection and analysis.

Light Weight - 1.4 kg
Wide Display and Easy Operation
Pipe Range : 13 - 5000 mm
Transducer can use : -20 - +120C degree
Weather-proof structure : IP65

Multi-Flow Measurement Function
Easy configurable for 2-Channel or 2-Path measurement


2-channel:Multi-flow measurement

2-path:Higher Stability




Energy Meter Function
Energy flow rate measurements with Pt100 RTD option.


Receiving-Echo Monitor Function
Visual confirmation that receiving echo is “good”.

Weather-proof structure IP65
IP65 rating maintained even during measurement.

USB Memory Data Transfer
Logged data and site conditions can be storaged into internal memory.


Language selection
You can choose
English, French, German, Italian,Japanese, Portuguese, Russian, Spanish, and Turkish.


Example of flowmeter or massmeter basic system




Example of heatmeter basic system


back

*Design and specifications are subject to change without notice.
